Grow lighting Electronic ballast manufacturer .Hydroponic/Greenhouse Grow lighting system supplier

grow lighting system

Grow lighting system for Euro market (230V/400V input)

E-ballast Model# Power Lamps Input voltage
HID-315w-230v 315W Grow lighting CDM/CMH/COSMO 165~265Vac
HID-400w-230v 400W Grow lighting CDM/CMH/COSMO 165~265V
HID-600w-230v 600W Grow lighting MH/HPS (Double ended/Single Ended) 165v~265V
HID-1000w-230v 1000W Grow lighting MH/HPS (Double ended/Single Ended) 165v~265v
HID-600w/1000w-400v 600w or 1000W Grow lighting MH/HPS (Double ended/Single Ended) 330v~440v

Grow lighting system for USA market (120V/208V/240V/277V/347V input)

E-ballast Model# Power Lamps Input voltage
HID-315w-120/208/240/277v 315W Grow lighting CDM/CMH/COSMO 90~265V or 200~315Vac
HID-400w-208/240/277v 400W Grow lighting CDM/CMH/COSMO 165~315V 120V need customized
HID-1000w-120/208/240v 1000W Grow lighting MH/HPS (Double ended/Single Ended) 90v~265V
HID-1000w-277/347v 1000W Grow lighting MH/HPS (Double ended/Single Ended) 240v~400v
HID-1500w-240/277v 1500W Grow lighting MH/HPS (Double ended/Single Ended) 175v~315v

We can manufacture new E-Ballasts/Reflectors which on diffrent input voltage and style according to the customers request

FCC Fart18 compliant

Patents - Growlighting system - Electronic ballast

Patent Number Registration Place Type of patent Date of patent
CN201310264577.9 USA Invention patent 2014.01.29
CN201310264577.9 CHINA Invention patent 2014.01.29
CN201320561354.4 CHINA utility model patent 2014.01.29
CN201320561361.4 CHINA utility model patent 2014.01.29
CN201320378021.8 CHINA utility model patent 2013.12.04
ZL201010191778.7 CHINA Invention patent 2010.06.04
Appl No Application Place Type of Patent Date of Approval
201510079388.3 CHINA Invention 2015.01
201520109189.8 CHINA Invention 2015.01
201520108325.1 CHINA Invention 2015.01
201520108325.1 CHINA Appearance 2015.01

Approval & Application Chars - Grow lighting system - Electronic ballast

Item Approval
EMI Fcc part 18
Safety Standard EN 60928, 60926
Quality Standard ISO 9001:2000
Environmental Standard ISO 14001
Harmonic current emissions IEC 61000-3-2
Vibrations IEC 68-2-6 Fc (10-150Hz, 2G)
Bumps IEC 68-2-29 Eb (10G/16ms)
Surge Protection EN61547 (L-L 2kV, L-G 4kV)

Key Components Selected - Grow lighting system - Electronic ballast

Brand Components Part No
CHEMI-CON electrolytic capacitor various
Rubycon
Faratronic capacitor various
ST MOSFET STW18NM80 TO-247
diode STTH810D
L6562AD,SO8
INFINEON M OSFET SPW35N60C3 P-TO-247
SPW17N80C3
ON IC SG3525ADWR2G
MICROCHIP single clip PIC16F690-I/SS
TYCO electric relay OZ-SS-112L1 12V
ST diode STTH810D
Pan Jit rectifier bridge KBJ2510,25A,1000V

Operating instructions

a) Before assembly&maintenance, please make sure the power is cut off

b) The product can work with HPS&MH&CDM lamps

c) The product for temperature between -30 to 50℃

d) When re-lamping, make sure lamp has time to cool before touching.

e) D O NOT make contact with the interior of the socket while power is on.

f) D O NOT attempt to rewire or reconfigure your system, it will void warranty and could cause serious safety

g) Keep away from children.

h) D O NOT submerse in water or splash water on the unit.
